1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15

    Buy cheap 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15 from wholesalers

    Buy cheap 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15 from wholesalers
    • Buy cheap 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15 from wholesalers
    • Buy cheap 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15 from wholesalers
    • Buy cheap 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15 from wholesalers

    1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15

    Ask Lasest Price
    Brand Name : VMAX
    Model Number : CPD15
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000unit / year
    Delivery Time : 45 DAYS
    • Product Details
    • Company Profile

    1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15

    Chinese 1.5 Ton 4 Wheel Drive Forklift / Small Electric Powered Forklift CPD15


    Four Wheel Electric Forklift Specifications

    1. ISO&CE certificate
    2. One year warranty
    3. OEM color & logo
    4. vmax forklift can meet the various specific requirements


    Specification 1.5 ton Four Wheel Electric Forklift
    ModelCPD15
    Load capacity kg1500
    Load center mm500
    Power typeBattery Powered(DC/AC)
    Max.lifting speeds(with load) mm/s285
    Max.Driving speeds(with without load) km/h12.5/14
    Max.Towing speeds(with load) kN6.5
    Gradeability(with load) %15
    Lifting height mm3000
    Free lift mm60
    Tilting angles(forward-backward) .6/12
    Min. turning radius mm1820
    Min. right angle aisle width mm1810
    Min. under-clearance mm95
    DimensionsA Overall length (inincluding fork) mm2960
    B Overall width mm1086
    H Overall height(mast lowered) mm2115
    H2 Overall height(mast extend) mm4015
    H3 Overall height to overhead guard mm2115
    B3 Fork width mm100
    H4 Fork thickness mm35
    A3 Fork length mm920(1070)
    A1 Fork overhang mm436
    A2 Wheel base mm1250
    TreadFront tread mm900
    Rear tread mm920
    TyreFront tyre6.50-10
    Rear tyre5.00-8
    Total weight kg3050
    MotorTraction motorXQ-5-4A3
    Lifting motorXQD-7.5-3C
    BatteryBattery typeD-440
    Battery voltage/Capacity V/Ah48/440

    OTHERS :

    A: date of delivery:15-25days after received the deposit
    B: payment terms:T/T(30% deposit,balance paid before shipment).Or L/C at sight
    C: Guaranty period: one year or 2000hours upon receiving goods.
