battery forklift truck 24V Stand-on ,1ton-2ton AC electric/battery
reach truck
VFA Series rated Load Capacity: 2000kg, lift height: 5000mm;
1. Speed Limited for high position, to avoid the possibility of
products' overturning when high speed in high position;
2. Curve safe control, the forklift will reduce the speed automatic
when turning, to aviod the ejection of operator and products from
the vehicle by the high speed;
3. Regenerative braking function to reduce the operation cost;
4. Safe cutoff valve, to protect the operator and goods in well
condition;
5. Shock Absorption of Pedal,to ensure the comfortable of working
and reduce the fatigue;
6. Reinforced Mast,to ensure the mast are not out of shape and lift
the goods smoothly;
7. Ergonomics multi-functional operation handle.
battery forklift truck specification:
| 24v Electric Reach truck |
| Description | VFA10-16 | VFA10-25 | VFA10-30 | VFA10-35 | VFA15-25 | VFA15-30 | VFA20-16 |
| Model No. |
| Load Capacity (KG) | 1000 | 1000 | 1000 | 1000 | 1500 | 1500 | 2000 |
| Load center MM | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| Max. Lifting Height (MM) | 1600 | 2500 | 3000 | 3500 | 2500 | 3000 | 1600 |
| Tyre | Solid tyre | Solid tyre | Solid tyre | Solid tyre | Solid tyre | Solid tyre | Solid tyre |
| Reach Stroke (MM) | 550 | 550 | 550 | 550 | 650 | 650 | 700 |
| Fork Size LxW (MM) | 1070*100 | 1070*100 | 1070*100 | 1070*100 | 1070*100 | 1070*120 |
| Between Forks (MM) | 220-600 | 220-600 | 220-600 | 220-600 | 220-600 | 220-600 | 260-660 |
| Overall Length without pedal (MM) | 2290 | 2290 | 2290 | 2290 | 2375 | 2375 | 2460 |
| Overall Width (MM) | 1090 | 1090 | 1090 | 1090 | 1090 | 1090 | 1090 |
| Height (MM)-Mast Lowered | 2140 | 1850 | 2100 | 2350 | 1850 | 2100 | 2140 |
| Height (MM)-Mast Extended | 2460 | 3360 | 3860 | 4360 | 3360 | 3860 | 2460 |
| Min. Turning Radius(MM) | 1630 | 1630 | 1630 | 1630 | 1800 | 1800 | 1930 |
| Travel Speed km/h-Laden/unladen | 4.0/5.0 | 4.0/5.0 | 4.0/5.0 | 4.0/5.0 | 4.0/5.0 | 4.0/5.0 | 4.0/5.0 |
| Min.Stacking Aisle(MM) (1000*1000 Pallet) | 2590 | 2590 | 2590 | 2590 | 2715 | 2715 | 2840 |
| Length of Pedal(mm) | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| Grade Ability % | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 |
| Driving Wheel (MM) | φ215*75 |
| Front Wheel (MM) | φ267*114 |
| Balance Wheel (MM) | φ150*50 |
| Battery V/Ah | 24/210 |
| Charger V/A | 24/30 |
| Driving Motor (KW) | 1.2 | 1.2 |
| Lifting Motor (KW) | 2 | 2 | 2 |
| Service Weight (with battery) KG | 1800 | 1840 | 1860 | 1880 | 1860 | 1880 | 1970 |
battery forklift truck Packaging & Shipping
A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment).
Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
Our Services
As a professional manufacturer of forklift, we also can offer you
customized service,
The following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage
full free mast of 4.5m/ 4.8m
Side shifter, fork positioner, longer forks, fork extension
For the details of customized configurations and options, please
contact with us.
VMAX professional service will be impressed on you.
